ADB-VWP is a pop out mount for video walls. The pop out functionality enables easy access for display maintenance and updates to media devices concealed behind the displays.

Each mount holds one display, and they are most often used to create video walls. Each bracket includes multiple points of fine tuning for perfect alignment of the display array.

Choose me for:

• Video walls with easy rear access
• Perfectly flush video walls in recessed spaces
• Retail and corporate environments

Features & specifications:

• Display capacity 110lb (50kg)
• Pop out spring lock/unlock
• Easy 'hook on' display attachment
• Pop out force control
  • 5 settings for varying screen weights
• Post-installation adjustment +/-0.39" (10mm)
  • In/out toolless adjustment at each corner
  • Up/down vertical adjustment
• Post-installation toolless +/-0.28" (7mm) lateral adjustment
• VESA universal to 400x400
  • to 600x400 or 400x600 with adaptor (included)
• Steel material with black finish
• Locking safety screws
  • Prevents display removable or dislodgement
• Lockable security point (requires padlock)

Suits media devices to 2.76" (70mm) depth mounted adjacent to bracket at rear.
